Drawings and information contained herein are for general purposes only and is not intended to replace OEM data. Individual BOP Data may differ from one BOP to another. Please verify all information prior to use. All values are from OEM’s most current operation / maintenance / user’s manual, as of spec binders published date.
BOP Shear Test Videos
Hydril Gk 13 5 8 Operation Manual download free Title: Hydril gx annular operator manual, Author: e672, Name: Hydril gx annular operator manual, Length: 4 pages, Page: 1, Published: 2018-01-25. Cfi annular gk type (like ge/hydril) 7-1/16”- 3m/5m/10m (gk type) 11”- 3m/5m/10m (gk type) 13-5/8”- 3m/5m/10m (gk type) 16-3/4”- 5m (gk type) 18-3/4”- 10m (gk type) cfi annular msp type. 20-1/2”- 2m (msp type) 20-3/4”- 3m (msp type) 21-1/4”- 5m (msp type) 29-1/2”- 500psi wp (msp type). It can be used at operating temperatures between -30℉ to 170℉ (-35 ℃ to 77 ℃). Neoprene rubber provides better service with oil-base drilling fluids than natural rubber. Hydril GK 13 5/8″ 5M Annular BOP No. Description: Part No. 1: 13 5/8″ 5M Annular BOP Seal Kit: 1002209: 1Set: 2: Packing Unit-Nitrile(NBR) 1003263-02: 1EA. 2 Type GK 13-5/8' 5K Annular BOP 3 Manufacturer Hydril 4 Height 54.125' / 1.375 m 5 Weight (Approximate - varies with connectors) 13,800 lbs. / 6259.575 kilograms 6 Clearance Diameter 52.25' / 1.327 m 7 Hydraulic operating pressure ≤ 1,500 PSI / 103.422 bar 8 Max hydraulic pressure 1,500 PSI / 103.422 bar.
BOP Spec Sheets
| VERTICAL BORE (INCHES) | PRESSURE RATING (PSI) | MANUFACTURER | ANNULAR TYPE | HEIGHT (INCHES) | WEIGHT APPROX (LBS) | CLEARANCE DIAMETER | MAX HYDRAULIC PRESSURE (PSI) | NPT PORT SIZE (INCHES) | NUMBER OF NPT PORTS | TO OPEN (GALLONS) | TO CLOSE (GALLONS) | STUDDED RING GASKET | FLANGE RING GASKET |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 7.063 | 5M | Cameron | T90 | 30.875 | 3.175 | 29.000 | 1,500 | 1.000 | 2 | 3.43 | 4.920 | RX-46 | RX-46 |
| 11.000 | 5M | Cameron | T90 | 41.500 | 9,550 | 44.750 | 1,500 | 1.250 | 2 | 14.59 | 18.670 | RX-54 | RX-54 |
| 11.000 | 5M | Cameron | T90 w/ 11'10M Flanged Bottom | 41.500 | 9,550 | 44.750 | 1,500 | 1.250 | 2 | 14.59 | 18.670 | RX-54 | BX158 |
| 13.625 | 10M | Cameron | DL w/ 13-5/8'15M Flanged Bottom | 49.094 | 27,262 | 61.000 | 1,500 | 1.250 | 4 | 16.15 | 18.100 | BX-159 | BX-159 |
| 7.063 | 5M | Hydril | GK Screwed | 36.880 | 4,000 | 35.750 | 1,500 | 1.000 | 2 | 3.30 | 3.860 | RX-46 | RX-46 |
| 7.063 | 10M | Hydril | GK Screwed | 48.130 | 12,200 | 49.500 | 1,500 | 1.000 | 2 | 7.08 | 9.420 | BX-156 | BX-156 |
| 11.000 | 5M | Hydril | GK Screwed | 47.810 | 8,200 | 44.250 | 1,500 | 1.000 | 2 | 7.98 | 9.810 | RX-54 | RX-54 |
| 11.000 | 10M | Hydril | GK Screwed | 63.500 | 26,140 | 61.500 | 1,500 | 1.000 | 2 | 18.97 | 25.100 | BX-158 | BX-158 |
| 13.625 | 5M | Hydril | GK Screwed | 54.130 | 13,800 | 52.250 | 1,500 | 1.000 | 2 | 14.16 | 17.980 | BX-160 | BX-160 |
| 16.750 | 5M | Hydril | GK Screwed | 61.250 | 20,835 | 59.500 | 1,500 | 1.000 | 2 | 19.93 | 28.700 | BX-162 | BX-162 |
| 18.750 | 5M | Hydril | GL w/ 18-3/4' 10M Flanged Bottom | 65.250 | 35,000 | 76.000 | 1,500 | 1.500 | 3 | 44.00 | 44.000 | BX-163 | BX-164 |
| 4.063 | 10M | Shaffer | Bolted | 25.500 | 1,850 | 23.000 | 1,500 | 0.750 | 2 | 1.99 | 2.400 | BX-155 | BX-155 |
| 7.063 | 5M | Shaffer | Bolted | 30.875 | 3,175 | 29.000 | 1,500 | 1.250 | 2 | 3.44 | 4.920 | RX-46 | RX-46 |
| 7.063 | 10M | Shaffer | Bolted | 42.250 | 10,600 | 43.000 | 1,500 | 1.500 | 2 | 14.13 | 17.300 | BX-156 | BX-156 |
| 11.000 | 5M | Shaffer | Bolted | 41.500 | 9,550 | 44.750 | 1,500 | 1.250 | 2 | 14.93 | 19.070 | RX-54 | RX-54 |
| 11.000 | 10M | Shaffer | Wedge | 53.000 | 23,000 | 57.000 | 1,500 | 2.000 | 2 | 24.67 | 30.580 | BX-158 | BX-158 |
| 11.000 | 10M | Shaffer | Wedge w/ 11'15M Flanged Bottom | 53.000 | 24,400 | 57.000 | 1,500 | 2.000 | 2 | 24.67 | 30.580 | BX-158 | BX-158 |
| 13.625 | 5M | Shaffer | Bolted | 44.938 | 13,650 | 50.000 | 1,500 | 1.500 | 2 | 18.48 | 24.990 | BX-160 | BX-160 |
| 13.625 | 5M | Shaffer | Bolted w/ 13-5/8'10M Flanged Bottom | 44.938 | 14,250 | 50.000 | 1,500 | 1.500 | 2 | 18.48 | 24.990 | BX-160 | BX-159 |
| 13.625 | 10M | Shaffer | Wedge | 58.750 | 32,475 | 64.500 | 1,500 | 2.000 | 4 | 32.64 | 40.16 | BX-159 | BX-159 |
| 16.750 | 5M | Shaffer | Wedge | 51.938 | 22,900 | 60.000 | 1,500 | 2.000 | 2 | 25.61 | 33.26 | BX-162 | BX-162 |
| 18.750 | 5M | Shaffer | Wedge w/ 18-3/4' 10M Flanged Bottom | 60.000 | 37,450 | 66.250 | 1,500 | 2.000 | 4 | 37.31 | 48.16 | BX-163 | BX-164 |
| 21.250 | 2M | Shaffer | Bolted | 46.125 | 10,850 | 49.000 | 1,500 | 1.500 | 2 | 17.95 | 34.47 | RX-73 | RX-73 |
| 30.000 | 1M | Shaffer | Bolted | 65.625 | 28,750 | 71.000 | 1,500 | 2.000 | 4 | 55.51 | 122.00 | RX-95 | RX-95 |
| VERTICAL BORE (INCHES) | PRESSURE RATING (PSI) | BOP TYPE | BONNET TYPE | HEIGHT (INCHES) | WEIGHT APPROX (LBS) | MAX HYDRAULIC PRESSURE (PSI) | OPEN / CLOSE PORT SIZE (INCHES) | FLANGE RING GASKET | OUTLET SIZE | OUTLET RING GASKET | BONNETS OPEN & UNLOCKED (INCHES) | BONNETS CLOSED & LOCKED (INCHES) | OPEN (GALLONS) | CLOSE (GALLONS) | OPEN RATIO | CLOSE RATIO |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 7.063 | 5M | Type U | Standard Bonnets | 27.500 | 4,697 | 3,000 | 1.000 | RX-46 | 2-1/16' 5M | RX-24 | 113.160 | 76.760 | 1.30 | 1.30 | 2.20 | 6.20 |
| 7.063 | 15M | Type U | Standard Bonnets | 31.810 | 5,557 | 3,000 | 1.000 | BX-156 | 2-1/16' 15M | BX-152 | 113.160 | 76.760 | 1.30 | 1.30 | 2.20 | 6.20 |
| 7.063 | 15M | Type U | UM Bonnets | 31.810 | 4,057 | 3,000 | 1.000 | BX-156 | 2-1/16' 15M | BX-152 | 116.500 | 78.250 | 2.20 | 2.30 | 3.80 | 11.70 |
| 11.000 | 5M | Type U | Standard Bonnets | 34.310 | 8,004 | 3,000 | 1.000 | RX-54 | 4-1/16' 5M | RX-39 | 149.760 | 97.060 | 3.40 | 3.50 | 2.50 | 7.30 |
| 11.000 | 5M | Type U | UM Bonnets | 34.310 | 6,504 | 3,000 | 1.000 | RX-54 | 4-1/16' 5M | RX-39 | 161.710 | 109.060 | 6.20 | 6.20 | 3.70 | 12.80 |
| 11.000 | 10M | Type U | Standard Bonnets | 35.690 | 8,643 | 3,000 | 1.000 | BX-158 | 4-1/16' 10M | BX-155 | 149.760 | 97.060 | 3.40 | 3.50 | 2.50 | 7.30 |
| 11.000 | 10M | Type U | UM Bonnets | 35.690 | 7,143 | 3,000 | 1.000 | BX-158 | 4-1/16' 10M | BX-155 | 146.875 | 96.250 | 6.20 | 6.20 | 3.70 | 12.80 |
| 11.000 | 15M | Type U | Standard Bonnets | 44.810 | 14,904 | 3,000 | 1.000 | BX-158 | 4-1/16' 15M | BX-155 | 182.110 | 122.020 | 5.70 | 5.80 | 2.20 | 9.80 |
| 13.625 | 5M | Type U | Standard Bonnets | 33.810 | 10,429 | 3,000 | 1.000 | BX-160 | 4-1/16' 5M | RX-39 | 173.810 | 113.670 | 5.50 | 5.80 | 2.30 | 6.80 |
| 13.625 | 10M | Type U | Standard Bonnets | 41.700 | 13,449 | 3,000 | 1.000 | BX-159 | 4-1/16' 10M | BX-155 | 175.540 | 115.660 | 5.50 | 5.80 | 2.30 | 6.80 |
| 13.625 | 15M | Type U | Standard Bonnets | 53.690 | 24,825 | 3,000 | 1.000 | BX-159 | 4-1/16' 15M | BX-155 | 206.890 | 132.370 | 10.40 | 10.60 | 3.70 | 10.30 |
| 16.750 | 5M | Type U | Standard Bonnets | 43.060 | 16,403 | 3,000 | 1.000 | BX-162 | 4-1/16' 5M | RX-39 | 203.640 | 129.000 | 9.80 | 10.60 | 2.30 | 6.80 |
| 16.750 | 10M | Type U | Standard Bonnets | 49.690 | 23,348 | 3,000 | 1.000 | BX-162 | 4-1/16' 10M | BX-155 | 220.000 | 138.730 | 11.60 | 12.50 | 2.30 | 6.80 |
| 16.750 | 10M | Type U | Large Bore w/ Booster | 49.690 | 25,178 | 3,000 | 1.000 | BX-162 | 4-1/16' 10M | BX-155 | 264.580 | 182.980 | 18.40 | 30.80 | 3.90 | 17.20 |
| 18.750 | 10M | Type U | Standard Bonnets | 55.940 | 28,727 | 3,000 | 1.000 | BX-164 | 4-1/16' 10M | BX-155 | 246.220 | 156.180 | 21.30 | 23.10 | 3.80 | 7.40 |
| 18.750 | 10M | Type U | Standard Bonnets w/ Boosters | 55.940 | 37,227 | 3,000 | 1.000 | BX-164 | 4-1/16' 10M | BX-155 | 298.540 | 208.500 | 21.60 | 47.10 | 5.00 | 15.10 |
| 21.250 | 5M | Type U | Standard Bonnets | 50.870 | 29,190 | 3,000 | 1.000 | BX-165 | 4-1/16' 5M | RX-39 | 251.360 | 164.070 | 27.30 | 30.00 | 4.00 | 7.20 |
| 21.250 | 5M | Type U | Standard Bonnets f/ Shearing | 50.870 | 29,190 | 3,000 | 1.000 | BX-165 | 4-1/16' 5M | RX-39 | 251.630 | 164.080 | 27.30 | 31.40 | 4.00 | 7.20 |
| 21.250 | 5M | Type U | Standard Bonnets w/ Booster | 50.870 | 39,000 | 3,000 | 1.000 | BX-165 | 4-1/16' 5M | RX-39 | 303.680 | 216.900 | 27.30 | 54.70 | 4.00 | 13.60 |
| 26.750 | 3M | Type U | Standard Bonnets | 48.310 | 28,683 | 3,000 | 1.000 | BX-168 | 4-1/16' 3M | RX-37 | 275.970 | 169.430 | 10.10 | 10.80 | 1.00 | 7.00 |
| VERTICAL BORE (INCHES) | PRESSURE RATING(PSI) | BOP TYPE | BONNET TYPE | HEIGHT (INCHES) | WEIGHT APPROX (LBS) | MAX HYDRAULIC PRESSURE (PSI) | OPEN/CLOSE PORT SIZE (INCHES) | FLANGE RING GASKET | OUTLET SIZE | OUTLET RING GASKET | UPPER | LOWER | |||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| UPPER | LOWER | BONNETS OPEN & UNLOCKED (INCHES) | BONNETS CLOSED & LOCKED (INCHES) | OPERATING DATA OPEN (GALLONS) | OPERATING DATA CLOSE (GALLONS) | OPEN RATIO | CLOSE RATIO | BONNETS OPEN & UNLOCKED (INCHES) | BONNETS CLOSED & LOCKED (INCHES) | OPERATING DATA OPEN (GALLONS) | OPERATING DATA CLOSE (GALLONS) | OPEN RATIO | CLOSE RATIO | ||||||||||
| 7.063 | 5M | Type U | Standard | Large Bore w/ Booster | 44.190 | 10,187 | 3,000 | 1.000 | RX-46 | 2-1/16' 5M | RX-24 | 113.160 | 76.760 | 1.300 | 1.300 | 2.200 | 6.200 | 146.790 | 109.850 | 2.400 | 4.100 | 4.400 | 17.300 |
| 7.063 | 15M | Type U | Standard | UM w/ Booster | 49.890 | 11,466 | 3,000 | 1.000 | BX-156 | 2-1/16' 15M | BX-152 | 113.160 | 76.760 | 1.300 | 1.300 | 2.200 | 6.200 | 154.700 | 116.330 | 2.200 | 3.900 | 3.800 | 18.700 |
| 11.000 | 5M | Type U | Standard | UM w/ Booster | 54.500 | 16,801 | 3,000 | 1.000 | RX-54 | 4-1/16' 5M | RX-39 | 149.760 | 97.060 | 3.400 | 3.500 | 2.500 | 7.300 | 192.625 | 142.000 | 6.200 | 12.700 | 3.700 | 21.800 |
| 11.000 | 10M | Type U | Standard | UM w/ Booster | 55.870 | 17,573 | 3,000 | 1.000 | BX-158 | 4-1/16' 10M | BX-155 | 149.760 | 97.060 | 3.400 | 3.500 | 2.500 | 7.300 | 195.625 | 145.000 | 6.200 | 12.700 | 3.700 | 21.800 |
| 11.000 | 15M | Type U | Standard | Large Bore w/ Booster | 69.750 | 28,772 | 3,000 | 1.000 | BX-158 | 4-1/16' 15M | BX-155 | 182.110 | 122.020 | 5.700 | 5.800 | 2.200 | 9.800 | 221.020 | 157.040 | 8.900 | 15.600 | 3.400 | 25.700 |
| 13.625 | 5M | Type U | Standard | Large Bore w/ Booster | 55.870 | 22,357 | 3,000 | 1.000 | BX-160 | 4-1/16' 5M | RX-39 | 173.810 | 113.670 | 5.500 | 5.800 | 2.300 | 6.800 | 219.200 | 158.230 | 10.500 | 17.500 | 3.700 | 17.200 |
| 13.625 | 10M | Type U | Standard | Large Bore w/ Booster | 66.630 | 26,810 | 3,000 | 1.000 | BX-159 | 4-1/16' 10M | BX-155 | 175.540 | 115.660 | 5.500 | 5.800 | 2.300 | 6.800 | 220.920 | 160.240 | 10.500 | 17.500 | 3.700 | 17.200 |
| 13.625 | 15M | Type U | Standard | Large Bore w/ Booster | 81.750 | 49,782 | 3,000 | 1.000 | BX-159 | 4-1/16' 15M | BX-155 | 206.890 | 132.370 | 10.400 | 10.600 | 3.700 | 10.300 | 251.450 | 176.540 | 16.000 | 27.700 | 5.600 | 25.800 |
| 16.750 | 5M | Type U | Standard | Large Bore w/ Booster | 68.810 | 35,673 | 3,000 | 1.000 | BX-162 | 4-1/16' 5M | RX-39 | 203.640 | 129.000 | 9.800 | 10.600 | 2.300 | 6.800 | 254.840 | 180.290 | 18.400 | 30.700 | 3.900 | 17.200 |
| 16.750 | 10M | Type U | Standard | Large Bore w/ Booster | 77.750 | 49,609 | 3,000 | 1.000 | BX-162 | 4-1/16' 10M | BX-155 | 220.000 | 138.730 | 11.600 | 12.500 | 2.300 | 6.800 | 264.580 | 182.980 | 18.400 | 30.800 | 3.900 | 17.200 |
| 18.750 | 10M | Type U | Standard | Large Bore w/ Booster | 86.970 | 62,878 | 3,000 | 1.000 | BX-164 | 4-1/16' 10M | BX-155 | 246.220 | 156.180 | 21.300 | 23.100 | 3.800 | 7.400 | 296.910 | 207.040 | 30.400 | 52.200 | 3.800 | 17.900 |
| 21.250 | 5M | Type U | Standard | Large Bore w/ Booster | 81.940 | 62,327 | 3,000 | 1.000 | BX-165 | 4-1/16' 5M | RX-39 | 251.360 | 164.070 | 27.300 | 30.000 | 4.000 | 7.200 | 306.760 | 218.330 | 34.800 | 62.200 | 4.000 | 15.300 |
Natural Rubber is compounded for drilling with water-base drilling fluids. Natural rubber can be used at operating temperatures between -30 ℉ to 225 ℉ (-35℃ to 107℃). When properly applied, the compounded natural rubber seal element will usually provide the longest service life.
Hydril Gk 13 5 8 Operation Manual Download
The seal element is all-black seal element identified with the suffix ”NR”.
Nitrile Rubber (a synthetic compound) is for use with oil-base or oil-additive drilling fluids. It provides the best service with
oil-base mud, when operated at temperatures between 20 ℉ to 190℉ (-7℃
to 88 ℃). The nitrile rubber seal element is identified by a red color band with the suffix “NBR”.
Neoprene Rubber is for low-temperature operating servic
e and oil-base drilling fluids. It can be used at operating temperatures between -30℉ to 170℉ (-35 ℃ to 77 ℃). Neoprene rubber provides better service with oil-base drilling fluids than natural rubber. It has better cold temperature elasticity than nitrile rubber; but, it is detrimentally a affected by extended high temperature applications. A neoprene packing unit should be used when natural rubber or synthetic rubber will not satisfy the operational conditions. The neoprene seal element is identified by a green band with the suffix “CR”.
Seals for CAMTOP BOPs are manufactured from a special nitrile rubber material which provides long, trouble-free service in sealing against oil, gas, or water.
Note:
Hydril Gk 13 5 8 Operation Manual Diagram
Expected H2S Service does not affect selection of seal element material. H2S service will reduce the service life of rubber products, but the best overall service life is obtained by matching the packing unit material with requirements of the specific drilling fluid.
